Front of card
Back of card
Furnish New Battery Ritar OPzV Series OPzV02 2500 V0 F10 T
Technology: Pb_Ca_Sn_VRLA_GEL.pngFurnish New Battery Ritar OPzV Series OPzV02 2500 V0 F10 T
$2,558.79
Build my Battery
Recycle My Battery
Furnish New Battery Ritar OPzV Series OPzV02 2500 V0 F10 T
| Battery Model | Ritar OPzV Series OPzV02 2500 V0 F10 T |
|---|---|
| Adjustment | 0.833333333 |
| AH Per String | 2500 |
| AH Per String Rating | 8 hr @ 1.75 VPC |
| Cells Per Unit | 1 |
| Nominal VPC | 2 |
| Model KWH | 5 |
| Charge VPC | 2.4 (Min: 2.37, Max: 2.4) |
| Discharge VPC | Min: 1.6, Max: 1.9 |
| Operational Temp Comp | -0.003 V/°C/cell |
| Cycle Temp Comp | -0.004 V/°C/cell |
| Discharge Temp Range | -15°C to 50°C |
| Charge Temp Range | -17.778°C to 40°C |
| ISC Amps | 9000 |
| Internal Resistance | 0.00012 Ohms |
| Dimensions (L x W x H) | 19.17 x 8.35 x 31.77 in |
| Weight | 419 lbs |
| Number of Posts | 4 |
| Terminal Bolt Diameter | 0.3149 in (M8 mm) |
| Torque (Initial / Maintenance) | 110 / 125 in-lbs |
| Container | V0 |
| Terminal | F10 |
| FOB | T |
| Max Continuous Discharge | 7500 Amps |
| Max Charge Amps | 750 Amps |
| Max In Series / Parallel | 0 / 0 |
| Watts Per Cell (15min 1.67) | 3989 |
| Watts Per Cell Rating | 15 min @ 1.67 VPC |
| Weight of Electrolyte | 110.2779003 lbs |
